Fabric Code: tpr295a

Samoan ferromagnesian crystal

Subset of Samoan ferromagnesian. Olivines equal or more than pyroxenes. Vitric and picritic basaltic lithics. Oliviines often altered to iddingsite.

Fabric Class:

Igneous Olivine: Dominated by igneous lithic inclusions with olivines.

Oceanic Basalt: Mainly contain olivines, clinopyroxenes and plagioclase, and have lathwork and mafic vitric lithic fragments.

Sites:

Ceramic Wares

Samoa Eastern Lapita (2800 - 2700 BP)

Mineral and Rock Abundances

None (0)	Minor (1)	Few (2)	Common (3)	Frequent (4)	Major (5)	Very Dominant (6)
0%	0-5%	5-15%	15-30 %	30-50%	50-70%	70-100%

Name	Cal.	Quartz	Feldspar	Pyroxene	Amphibole	Opaques	Olivine	Biotite	Muscovite	Epidote	Garnet/ Spinel	Ig./Met. Rocks	Sed. Rocks	Grog	Lithics/ Region
Max	3	1	1	4	0	0	4	0	0	0	0	4	0	0	lathwork, vitric
Min	0	0	0	2	0	0	3	0	0	0	0	3	0	0	Samoa

Representative slides:

Slide	Site	Possible Origin	Ware	Cal.	Quartz	Feldspar	Pyroxene	Amphibole	Opaques	Olivine	Biotite	Muscovite	Epidote	Garnet/ Spinel	Ig./Met. Rocks	Sed. Rocks	Grog	Lithics
FP_1_8	Mulifanua (Upolu)	Upolu	Samoa Eastern Lapita (2800 - 2700 BP)	1	0	0	2	0	0	3	0	0	0	0	4	0	0	lathwork, vitric
FP_1_15	Mulifanua (Upolu)	Upolu	Samoa Eastern Lapita (2800 - 2700 BP)	1	0	0	3	0	0	4	0	0	0	0	4	0	0	lathwork, vitric
FP_1_16	Mulifanua (Upolu)	Upolu	Samoa Eastern Lapita (2800 - 2700 BP)	0	0	0	4	0	0	4	0	0	0	0	3	0	0	lathwork
FL_1_4	Mulifanua (Upolu)	Upolu	Samoa Eastern Lapita (2800 - 2700 BP)	0	0	0	3	0	0	3	0	0	0	0	4	0	0	lathwork, vitric
WD_23_3	Mulifanua (Upolu)	Samoa	Samoa Eastern Lapita (2800 - 2700 BP)	0	0	1	3	0	1	4	0	0	0	0	4	0	0	lathwork, microlitic
WD_23_6	Mulifanua (Upolu)	Samoa	Samoa Eastern Lapita (2800 - 2700 BP)	3	0	1	2	0	1	3	0	0	0	0	4	0	0	lathwork, microlitic
WD_23_8	Mulifanua (Upolu)	Samoa	Samoa Eastern Lapita (2800 - 2700 BP)	0	0	1	2	0	1	3	0	0	0	0	4	0	0	lathwork, microlitic
WD_23_9	Mulifanua (Upolu)	Samoa	Samoa Eastern Lapita (2800 - 2700 BP)	2	0	1	3	0	1	4	0	0	0	0	4	0	0	lathwork, microlitic

FP_1_8

Mulifanna_23v252 — Sherd 23-252 from Mulifanua (Upolu). Slide FP_1_8 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanna_23v252 — Sherd 23-252 from Mulifanua (Upolu). Slide FP_1_8 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Oxidised sherd. Has trace quartz and feldspars from Fagaloa formation.

FP_1_15

Mulifanna_30v151 — Sherd 30-151 from Mulifanua (Upolu). Slide FP_1_15 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanna_30v151 — Sherd 30-151 from Mulifanua (Upolu). Slide FP_1_15 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Oxidised sherd. Picritic lithics. Altered olivines. More olivines than pyroxenes.

FP_1_16

Mulifanna_30v330 — Sherd 30-330 from Mulifanua (Upolu). Slide FP_1_16 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanna_30v330 — Sherd 30-330 from Mulifanua (Upolu). Slide FP_1_16 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Oxidised sherd. Equal olivines and pyroxenes. Mainly picritic basaltic lithics.

FL_1_4

Mulifauna_509 — Sherd 509 from Mulifanua (Upolu). Slide FL_1_4 from Leach Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Mulifauna_509 — Sherd 509 from Mulifanua (Upolu). Slide FL_1_4 from Leach Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Ferromagnesian.

WD_23_3

Mulifanua_SU_P18_19 — Sherd SU/P18/19 from Mulifanua (Upolu). Slide WD_23_3 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanua_SU_P18_19 — Sherd SU/P18/19 from Mulifanua (Upolu). Slide WD_23_3 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Crystal lithic beach sand.

WD_23_6

Mulifanua_SU_P18_56 — Sherd SU/P18/56 from Mulifanua (Upolu). Slide WD_23_6 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanua_SU_P18_56 — Sherd SU/P18/56 from Mulifanua (Upolu). Slide WD_23_6 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Crystal lithic.

WD_23_8

Mulifanua_SU_P18_77 — Sherd SU/P18/77 from Mulifanua (Upolu). Slide WD_23_8 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanua_SU_P18_77 — Sherd SU/P18/77 from Mulifanua (Upolu). Slide WD_23_8 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Crystal lithic beach sand.

WD_23_9

Mulifanua_SU_P18_79 — Sherd SU/P18/79 from Mulifanua (Upolu). Slide WD_23_9 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Mulifanua_SU_P18_79 — Sherd SU/P18/79 from Mulifanua (Upolu). Slide WD_23_9 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Crystal lithic beach sand.

References:

Petchey MA Thesis 1995 (Petchey, F.)
