Fabric Code: tpr83

Halmahera volcanic

Well sorted and variably abraded volcanic sand temper.

Sites:

Mineral and Rock Abundances

None (0) Minor (1) Few (2) Common (3) Frequent (4) Major (5) Very Dominant (6)
0% 0-5% 5-15% 15-30 % 30-50% 50-70% 70-100%

Name Cal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ SpinelIg./Met. Rocks Sed. Rocks Grog Lithics/ Region
Max 0 0 4 2 1 2 0 0 0 0 0 3 0 0 felsitic, microlitic, lathwork
Min 0 0 4 2 1 1 0 0 0 0 0 4 0 0 Maluku

Representative slides:

Slide Site Possible OriginCal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ Spinel Ig./Met. Rocks Sed. Rocks Grog Lithics
WD_20_21 Makian (Makian) Halmahera 0 0 4 2 1 1 0 0 0 0 0 3 0 0 felsitic, microlitic
WD_20_20 Makian (Makian) Halmahera 0 0 4 2 1 2 0 0 0 0 0 3 0 0 felsitic, microlitic, lathwork
WD_20_22 Kayoa (Kayoa) Halmahera 0 0 4 2 1 1 0 0 0 0 0 3 0 0 felsitic, microlitic, lathwork
WD_20_24 Gebe (Gebe) Halmahera 0 0 4 2 1 1 0 0 0 0 0 3 0 0 microlitic, felsitic, lathwork

WD_20_21

Halmahera_74_2 Halmahera_74_2
Sherd 74-2 from Makian (Makian). Slide WD_20_21 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Well sorted and variably abraded volcanic sand temper. Plagioclase, varied lithics, clinopyroxene, opaques, hornblende.


WD_20_20

Halmahera_74_1 Halmahera_74_1
Sherd 74-1 from Makian (Makian). Slide WD_20_20 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Volcanic sand temper.


WD_20_22

Halmahera_74_3 Halmahera_74_3
Sherd 74-3 from Kayoa (Kayoa). Slide WD_20_22 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Volcanic sand temper.


WD_20_24

Halmahera_74_5 Halmahera_74_5
Sherd 74-5 from Gebe (Gebe). Slide WD_20_24 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Volcanic sand.


References:

220 Aru, Halmahera, 2002 (Dickinson, W.)
