| None (0) | Minor (1) | Few (2) | Common (3) | Frequent (4) | Major (5) | Very Dominant (6) |
| 0% | 0-5% | 5-15% | 15-30 % | 30-50% | 50-70% | 70-100% |
| Name | Cal. | Quartz | Feldspar | Pyroxene | Amphibole | Opaques | Olivine | Biotite | Muscovite | Epidote | Garnet/ Spinel | Ig./Met. Rocks | Sed. Rocks | Grog | Lithics/ Region |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| tpr50 | 0 | 2 | 3 | 1 | 0 | 4 | 0 | 0 | 0 | 0 | 0 | 3 | 0 | 3 | felsitic, vitric, microlitic |
| Palau grog type B/C/D | 0 | 2 | 3 | 1 | 0 | 4 | 0 | 0 | 0 | 0 | 0 | 3 | 0 | 1 | Carolines |
| Slide | Fabric | Possible Origin | Cal. | Quartz | Feldspar | Pyroxene | Amphibole | Opaques | Olivine | Biotite | Muscovite | Epidote | Garnet/ Spinel | Ig./Met. Rocks | Sed. Rocks | Grog | Lithics |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| WD_13_17 | tpr50 (Palau grog type B/C/D) | Babeldoab | 0 | 2 | 3 | 1 | 0 | 4 | 0 | 0 | 0 | 0 | 0 | 3 | 0 | 3 | felsitic, microlitic |
'Type B' Palauan temper type; hybrid feldspathic-lithic sand temper composed of mixed volcanic and calcareous sand.
