Site: Jane's Camp

Island: Upolu


Fabrics:

None (0) Minor (1) Few (2) Common (3) Frequent (4) Major (5) Very Dominant (6)
0% 0-5% 5-15% 15-30 % 30-50% 50-70% 70-100%

Name Cal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ SpinelIg./Met. Rocks Sed. Rocks Grog Lithics/ Region
tpr295 0 0 1 5 0 3 4 0 0 0 0 6 0 0 lathwork, vitric
Samoan ferromagnesian beach 0 0 0 3 0 1 2 0 0 0 0 3 0 0 Samoa
tpr291 3 0 2 3 1 3 3 1 0 0 0 6 0 0 lathwork, vitric
Samoan lithic 0 0 0 1 0 0 1 0 0 0 0 4 0 0 Samoa
tpr290b 0 0 5 2 0 2 0 0 0 0 0 6 0 0 lathwork, vitric
Samoan crushed lathwork lithic 0 0 3 0 0 1 0 0 0 0 0 4 0 0 Samoa
tpr293b 1 0 2 1 2 0 1 0 0 0 0 6 0 0 microlitic, lathwork, vitric
Samoan microlitic trachytic 0 0 0 0 0 0 0 0 0 0 0 5 0 0 Samoa

Slides:

Slide Fabric Possible OriginCal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ Spinel Ig./Met. Rocks Sed. Rocks Grog Lithics
WD_25_5 tpr293b (Samoan microlitic trachytic) Samoa 0 0 2 0 0 0 1 0 0 0 0 6 0 0 microlitic, lathwork
WD_23_24 tpr295 (Samoan ferromagnesian beach) Samoa 0 0 0 3 0 3 4 0 0 0 0 3 0 0 lathwork
WD_22_4 tpr290b (Samoan crushed lathwork lithic) Samoa 0 0 4 0 0 2 0 0 0 0 0 4 0 0 lathwork, microlitic
WD_22_3 tpr290b (Samoan crushed lathwork lithic) Samoa 0 0 3 0 0 2 0 0 0 0 0 6 0 0 lathwork, microlitic
WD_22_1 tpr290b (Samoan crushed lathwork lithic) Samoa 0 0 4 0 0 1 0 0 0 0 0 5 0 0 lathwork, microlitic

WD_25_5

JanesCamp_FS84 JanesCamp_FS84
Sherd SuFL-1 FS-84 from Jane's Camp (Upolu). Slide WD_25_5 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Trachytic microlitic.


WD_23_24

JanesCamp_31_2 JanesCamp_31_2
Sherd SuFL-1 FS-31-2 from Jane's Camp (Upolu). Slide WD_23_24 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image or full slide in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Ferromagnetic.


WD_22_4

JanesCamp_147_4_a JanesCamp_147_4_a
Sherd 75147-4 from Jane's Camp (Upolu). Slide WD_22_4 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image or full slide in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Crushed rock.


WD_22_3

JanesCamp_129_2 JanesCamp_129_2
Sherd SUFL-1 FS-129-2 from Jane's Camp (Upolu). Slide WD_22_3 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Crushed rock.


WD_22_1

JanesCamp_52_3 JanesCamp_52_3
Sherd SUFL-1 FS-52-3 from Jane's Camp (Upolu). Slide WD_22_1 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Crushed rock.
