Fabric Code: tpr333

Navatu partially placered

Contains hypabassal dolerite.

Sites:

Mineral and Rock Abundances

None (0) Minor (1) Few (2) Common (3) Frequent (4) Major (5) Very Dominant (6)
0% 0-5% 5-15% 15-30 % 30-50% 50-70% 70-100%

Name Cal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ SpinelIg./Met. Rocks Sed. Rocks Grog Lithics/ Region
Max 0 0 3 5 1 2 2 1 0 1 0 3 0 0 lathwork, microlitic, vitric, microphaneritic, plutonite
Min 0 0 2 4 0 1 1 0 0 0 0 2 0 0 Fiji

Representative slides:

Slide Site Possible OriginCal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ Spinel Ig./Met. Rocks Sed. Rocks Grog Lithics
WD_54_23 Navatu (Viti Levu) Viti Levu 0 0 2 5 1 1 1 1 0 0 0 3 0 0 lathwork, microlitic, vitric, microphaneritic, plutonite
WD_54_25 Navatu (Viti Levu) Viti Levu 0 0 3 5 1 1 2 0 0 1 0 2 0 0 lathwork, microlitic, vitric, microphaneritic,
WD_54_7 Navatu (Viti Levu) Viti Levu 0 0 3 4 0 2 2 1 0 1 0 3 0 0 lathwork, microlitic, vitric, microphaneritic

WD_54_23

Navatu_NAV12A Navatu_NAV12A
Sherd NAV12A from Navatu (Viti Levu). Slide WD_54_23 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Basaltic sand temper derived from bedrock of the Pliocene Ba Volcanic Group; Indigenous temper to Viti Levu.


WD_54_25

Navatu_NAV109 Navatu_NAV109
Sherd NAV109 from Navatu (Viti Levu). Slide WD_54_25 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Punctate sherd with finger-impressed rim; Pyroxenic temper sand that is partially- to fully-placered.


WD_54_7

Navatu_17_7 Navatu_17_7
Sherd 17-7 from Navatu (Viti Levu). Slide WD_54_7 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Partially placered.


References:

188 Viti Levu, Fiji, 1999 (Dickinson, W.)

171 Navatu, Viti Levu, Fiji 1998 (Dickinson, W.)
