Fabric Code: tpr341e

Sigatoka quartzose E

Low lithic quartzose fabric.

Fabric Class:

Quartzose-Feldspathic Lithic: Dominated by quartz and feldspar inclusions, with igneous and/or sedimentary lithics.

Dissected Orogen: Dominated by plutonic lithics such as microgranite, and those with microphaneritic textures, as well as metavolcanics. They have K-feldspars dominate, in addition to plagioclase.

Sites:

Mineral and Rock Abundances

None (0) Minor (1) Few (2) Common (3) Frequent (4) Major (5) Very Dominant (6)
0% 0-5% 5-15% 15-30 % 30-50% 50-70% 70-100%

Name Cal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ SpinelIg./Met. Rocks Sed. Rocks Grog Lithics/ Region
Max 0 4 4 3 2 3 0 1 0 0 0 2 2 0 quartzite, microlitic, argillitic, chert, siltstone, tectonite
Min 0 3 2 2 0 2 0 0 0 0 0 0 1 0 Fiji

Representative slides:

Slide Site Possible OriginCal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ Spinel Ig./Met. Rocks Sed. Rocks Grog Lithics
FP_1_21 Sigatoka (Viti Levu) Sigatoka 0 4 4 2 1 2 0 1 0 0 0 0 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_23 Sigatoka (Viti Levu) Sigatoka 0 3 4 3 1 2 0 0 0 0 0 2 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_24 Sigatoka (Viti Levu) Sigatoka 0 3 4 3 1 2 0 1 0 0 0 2 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_25 Sigatoka (Viti Levu) Sigatoka 0 3 4 2 1 3 0 0 0 0 0 2 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_27 Sigatoka (Viti Levu) Sigatoka 0 3 3 3 1 2 0 0 0 0 0 2 1 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_28 Sigatoka (Viti Levu) Sigatoka 0 3 4 2 2 3 0 0 0 0 0 2 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_30 Sigatoka (Viti Levu) Sigatoka 0 2 4 2 1 2 0 0 0 0 0 2 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic
FP_1_31 Sigatoka (Viti Levu) Sigatoka 0 3 3 3 1 2 0 0 0 0 0 1 2 0 microlitic, microphaneritic, argillitic, silstone, chert, quartzite, felsitic

FP_1_21

Sigatoka_42a_3 Sigatoka_42a_3
Sherd 42a-3 from Sigatoka (Viti Levu). Slide FP_1_21 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_23

Sigatoka_44a_16 Sigatoka_44a_16
Sherd 44a-16 from Sigatoka (Viti Levu). Slide FP_1_23 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_24

Sigatoka_44a_66 Sigatoka_44a_66
Sherd 44a-66 from Sigatoka (Viti Levu). Slide FP_1_24 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_25

Sigatoka_44b_4 Sigatoka_44b_4
Sherd 44b-4 from Sigatoka (Viti Levu). Slide FP_1_25 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_27

Sigatoka_45a_171_a Sigatoka_45a_171_a
Sherd 45a-171-1 from Sigatoka (Viti Levu). Slide FP_1_27 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_28

Sigatoka_45a_429 Sigatoka_45a_429
Sherd 45a-429 from Sigatoka (Viti Levu). Slide FP_1_28 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_30

Sigatoka_45a_1222_a Sigatoka_45a_1222_a
Sherd 45a-1222-a from Sigatoka (Viti Levu). Slide FP_1_30 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


FP_1_31

Sigatoka_46x_103 Sigatoka_46x_103
Sherd 46x-103 from Sigatoka (Viti Levu). Slide FP_1_31 from Petchey Collection, Auckland University. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Indigenous Sigatoka sherds. Feldspars include K-feldspars as well as plagioclase. 1973 excavated samples.


References:

Petchey MA Thesis 1995 (Petchey, F.)
