Fabric Code: tpr380

Vava'u parially placered

Has orthopyroxene and clinopyroxenes.

Sites:

Mineral and Rock Abundances

None (0) Minor (1) Few (2) Common (3) Frequent (4) Major (5) Very Dominant (6)
0% 0-5% 5-15% 15-30 % 30-50% 50-70% 70-100%

Name Cal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ SpinelIg./Met. Rocks Sed. Rocks Grog Lithics/ Region
Max 0 0 3 5 0 1 0 0 0 0 0 4 0 0 microlitic, felsitic, vitric
Min 0 0 3 4 0 2 0 0 0 0 0 3 0 0 Tonga

Representative slides:

Slide Site Possible OriginCal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ Spinel Ig./Met. Rocks Sed. Rocks Grog Lithics
WD_71_19 Kapa (Kapa) Vava'u 0 0 3 4 0 2 0 0 0 0 0 4 0 0 microlitic, vitric, felsitic
WD_71_24 Kapa (Kapa) Vava'u 0 0 3 4 0 2 0 0 0 0 0 4 0 0 microlitic, vitric, felsitic
WD_71_25 Hunga (Hunga) Vava'u 0 0 3 5 0 1 0 0 0 0 0 3 0 0 microlitic, felsitic

WD_71_19

Kapa_K11 Kapa_K11
Sherd K11 from Kapa (Kapa). Slide WD_71_19 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Plain. Partial pyroxenic.


WD_71_24

Kapa_36_16 Kapa_36_16
Sherd 36-16 from Kapa (Kapa). Slide WD_71_24 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image (user: Guest pwd: Guest) or full slide in VIMIPO. Imaged by K. Hardy and M. Leclerc, ANU.

Undecorated Lapitoid sherd. Partial pyroxenic.


WD_71_25

Hunga Hunga
Sherd HUNGA from Hunga (Hunga). Slide WD_71_25 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Partially placered sherd but with lower levels of opaques.


References:

182 Hunga, Vava'u, Tonga, 1999 (Dickinson, W.)

124 Kapa, Vava'u, Tonga, 1996 (Dickinson, W.)
