Fabric Code: tpr427

Haapi opaque

Orthopyroxene as well as clinopyroxene.

Fabric Class:

Opaque Pyroxenic: Dominated by opaque inclusions, with pyroxenes.

Andesitic Arc: Dominated by andesite and basalt lithic fragments, with microlitic, felsitic and vitric textures, and the andesite minerals (plagioclase, clinopyroxene and sometimes hornblende).

Sites:

Mineral and Rock Abundances

None (0)	Minor (1)	Few (2)	Common (3)	Frequent (4)	Major (5)	Very Dominant (6)
0%	0-5%	5-15%	15-30 %	30-50%	50-70%	70-100%

Name	Cal.	Quartz	Feldspar	Pyroxene	Amphibole	Opaques	Olivine	Biotite	Muscovite	Epidote	Garnet/ Spinel	Ig./Met. Rocks	Sed. Rocks	Grog	Lithics/ Region
Max	1	0	1	3	0	5	0	0	0	0	0	1	0	0	na
Min	1	0	1	3	0	5	0	0	0	0	0	1	0	0	Tonga

Representative slides:

Slide	Site	Possible Origin	Cal.	Quartz	Feldspar	Pyroxene	Amphibole	Opaques	Olivine	Biotite	Muscovite	Epidote	Garnet/ Spinel	Ig./Met. Rocks	Sed. Rocks	Grog	Lithics
WD_73_5	Faleloa (Foa)	Ha'apai	1	0	1	3	0	5	0	0	0	0	0	1	0	0	microlitic, vitric

WD_73_5

FaleloaFoa_83e — Sherd 83e from Faleloa (Foa). Slide WD_73_5 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

FaleloaFoa_83e — Sherd 83e from Faleloa (Foa). Slide WD_73_5 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Lapita sherd.

References:

Sand Tempers in Indigenous Lapita and Lapitoid Polynesian Plainware and Imported Protohistoric Fijia (Dickinson, W., Shutler, R., Shortland, R., Burley, D.V., Dye, T.S.)
