Site: Naigani

Island: Naigani


Fabrics:

None (0) Minor (1) Few (2) Common (3) Frequent (4) Major (5) Very Dominant (6)
0% 0-5% 5-15% 15-30 % 30-50% 50-70% 70-100%

Name Cal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ SpinelIg./Met. Rocks Sed. Rocks Grog Lithics/ Region
tpr171 0 5 4 2 2 1 0 1 0 1 0 3 2 0 microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
Rewa Delta orogen 0 3 2 1 1 0 0 0 0 0 0 1 1 0 Fiji
tpr364 0 0 2 5 0 2 2 0 0 0 0 3 0 0 lathwork
Kedekeke pyroxenic 0 0 0 6 0 0 0 0 0 0 0 1 0 0 Fiji
tpr367 0 0 2 6 3 2 1 0 0 0 0 3 0 0 microlitic, lathwork
Moturiki pyribole placer 0 0 1 5 1 1 0 0 0 0 0 1 0 0 Fiji
tpr368 6 0 0 0 0 0 0 0 0 0 0 0 0 0 na
Naigani calcareous 6 0 0 0 0 0 0 0 0 0 0 0 0 0 Fiji

Slides:

Slide Fabric Possible OriginCal. QuartzFeldspar Pyroxene Amphibole Opaques OlivineBiotite Muscovite Epidote Garnet/ Spinel Ig./Met. Rocks Sed. Rocks Grog Lithics
WD_67_26 tpr367 (Moturiki pyribole placer) Moturiki 0 0 2 5 3 1 0 0 0 0 0 3 0 0 microlitic, lathwork
WD_67_27 tpr367 (Moturiki pyribole placer) Moturiki 0 0 1 6 2 2 0 0 0 0 0 1 0 0 microlitic, lathwork

WD_67_26

Naigani_VL_13C5 Naigani_VL_13C5
Sherd VL13C5 from Naigani (Naigani). Slide WD_67_26 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image or full slide in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Pyroxenic placer.


WD_67_27

Naigani_VL_9B6 Naigani_VL_9B6
Sherd VL_9B6 from Naigani (Naigani). Slide WD_67_27 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Pyroxenic placer.


References:

159 Naigaini, Lomaiviti, Fiji (Dickinson, W.)
