Site: Nasilai

Island: Viti Levu

Fabrics:

None (0)	Minor (1)	Few (2)	Common (3)	Frequent (4)	Major (5)	Very Dominant (6)
0%	0-5%	5-15%	15-30 %	30-50%	50-70%	70-100%

Name	Cal.	Quartz	Feldspar	Pyroxene	Amphibole	Opaques	Olivine	Biotite	Muscovite	Epidote	Garnet/ Spinel	Ig./Met. Rocks	Sed. Rocks	Grog	Lithics/ Region
tpr171	0	5	4	2	2	1	0	1	0	1	0	3	2	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
Rewa Delta orogen	0	3	2	1	1	0	0	0	0	0	0	1	1	0	Fiji
tpr347	4	0	2	4	0	2	0	1	0	0	0	1	0	0	na
Exotic Nasilai hybrid	4	0	2	4	0	2	0	0	0	0	0	1	0	0	Fiji
tpr348b	4	0	5	2	3	3	0	2	0	0	0	3	0	0	felsitic, lathwork, microlitic, vitric
Kadavu hornblendic	0	0	2	0	2	1	0	0	0	0	0	1	0	0	Fiji

Slides:

Slide	Fabric	Possible Origin	Cal.	Quartz	Feldspar	Pyroxene	Amphibole	Opaques	Olivine	Biotite	Muscovite	Epidote	Garnet/ Spinel	Ig./Met. Rocks	Sed. Rocks	Grog	Lithics
WD_65_21	tpr348b (Kadavu hornblendic)	Central Kadavu	0	0	5	1	2	2	0	1	0	0	0	3	0	0	felsitic, vitric, microlith
WD_65_22	tpr348b (Kadavu hornblendic)	Kadavu	0	0	5	0	3	1	0	1	0	0	0	2	0	0	vitric, felsitic, microlitic
WD_62_1	tpr171 (Rewa Delta orogen)	Nasilai	0	4	4	1	1	1	0	1	0	1	0	3	1	0	microphaneritic, vitric, microlitic, siltstone, tectonite, chert
WD_62_2	tpr171 (Rewa Delta orogen)	Nasilai	0	4	4	1	2	1	0	1	0	1	0	3	1	0	microphaneritic, vitric, microlitic, siltstone, tectonite, chert
WD_62_3	tpr171 (Rewa Delta orogen)	Nasilai	0	3	4	2	2	1	0	1	0	1	0	2	1	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_4	tpr171 (Rewa Delta orogen)	Nasilai	0	4	4	2	2	1	0	1	0	1	0	2	1	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_6	tpr171 (Rewa Delta orogen)	Nasilai	0	3	3	1	1	1	0	1	0	1	0	3	2	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_9	tpr171 (Rewa Delta orogen)	Nasilai	0	3	4	2	1	1	0	1	0	1	0	3	2	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_13	tpr171 (Rewa Delta orogen)	Nasilai	0	3	3	2	2	1	0	1	0	1	0	3	2	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_14	tpr171 (Rewa Delta orogen)	Nasilai	0	4	4	1	1	1	0	1	0	1	0	3	2	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_19	tpr171 (Rewa Delta orogen)	Nasilai	0	4	3	2	1	1	0	1	0	1	0	2	2	0	microphaneritic, felsitic, microlitic, siltstone, tectonite, chert
WD_62_21	tpr347 (Exotic Nasilai hybrid)	exotic	4	0	2	4	0	2	0	1	0	0	0	1	0	0	na
WD_62_22	tpr347 (Exotic Nasilai hybrid)	exotic	4	0	2	4	0	2	0	1	0	0	0	1	0	0	na

WD_65_21

Nasilai_N7 — Sherd N7 from Nasilai (Viti Levu). Slide WD_65_21 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N7 — Sherd N7 from Nasilai (Viti Levu). Slide WD_65_21 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Hornblendic with oxyhornblende.

WD_65_22

Nasilai_N17 — Sherd N17 from Nasilai (Viti Levu). Slide WD_65_22 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N17 — Sherd N17 from Nasilai (Viti Levu). Slide WD_65_22 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Imported from Kadavu. Has oxyhornblende in addition to hornblende. Possible western Kadavu source.

WD_62_1

Shaw_24_2 — Sherd 24-2 from Nasilai (Viti Levu). Slide WD_62_1 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Shaw_24_2 — Sherd 24-2 from Nasilai (Viti Levu). Slide WD_62_1 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen.

WD_62_2

Shaw_24_3 — Sherd 24-3 from Nasilai (Viti Levu). Slide WD_62_2 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Shaw_24_3 — Sherd 24-3 from Nasilai (Viti Levu). Slide WD_62_2 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_3

Nasilai_N_1 — Sherd N_1 from Nasilai (Viti Levu). Slide WD_62_3 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_1 — Sherd N_1 from Nasilai (Viti Levu). Slide WD_62_3 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_4

Nasilai_N_2 — Sherd N-2 from Nasilai (Viti Levu). Slide WD_62_4 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_2 — Sherd N-2 from Nasilai (Viti Levu). Slide WD_62_4 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_6

Nasilai_N_4 — Sherd N-4 from Nasilai (Viti Levu). Slide WD_62_6 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image or full slide in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_4 — Sherd N-4 from Nasilai (Viti Levu). Slide WD_62_6 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image or full slide in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_9

Nasilai_N_8 — Sherd N-8 from Nasilai (Viti Levu). Slide WD_62_9 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_8 — Sherd N-8 from Nasilai (Viti Levu). Slide WD_62_9 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_13

Nasilai_N_12 — Sherd N-12 from Nasilai (Viti Levu). Slide WD_62_13 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_12 — Sherd N-12 from Nasilai (Viti Levu). Slide WD_62_13 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_14

Nasilai_N_13 — Sherd N-13 from Nasilai (Viti Levu). Slide WD_62_14 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_13 — Sherd N-13 from Nasilai (Viti Levu). Slide WD_62_14 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_19

Nasilai_N_19 — Sherd N-19 from Nasilai (Viti Levu). Slide WD_62_19 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_19 — Sherd N-19 from Nasilai (Viti Levu). Slide WD_62_19 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Dissected orogen temper.

WD_62_21

Nasilai_N_21 — Sherd N-21 from Nasilai (Viti Levu). Slide WD_62_21 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_21 — Sherd N-21 from Nasilai (Viti Levu). Slide WD_62_21 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Exotic hybrid. Surface sherd.

WD_62_22

Nasilai_N_22 — Sherd N-22 from Nasilai (Viti Levu). Slide WD_62_22 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Nasilai_N_22 — Sherd N-22 from Nasilai (Viti Levu). Slide WD_62_22 from Dickinson Collection, Bishop Museum. x4 Magnification PPL (left) XPL (right). Scale bar: 0.5mm. High resolution image in VIMIPO (user: Guest pwd: Guest). Imaged by K. Hardy and M. Leclerc, ANU.

Exotic hybrid temper. Surface sherd.

References:

142 Nasilai, Rewa Delta, Viti Levu, Fiji 1997 (Dickinson, W.)

284 Kadavu, Fiji, 2010 (Dickinson, W.)
